Vehicle Bomb Signal Jammer System High Power Military Cell Phone
Signal Jammer
This type jammer protecting military and VIP convoys from the
threat of remote control improvised explosive devices
(RCIEDs)-road-side bombs has become a challenge and task in many
parts of the world.
High Power DDS Convoy Jamming System, implementing the most
effective and reliable RF jamming technology and equipped with a
fully-integrated broadband jamming system.
Beyond the installation of the convoy protection device itself, the
vehicle is customized with special RF protection for full
protection of the driver and passengers.System management,
including activation and controland operation is carried out
through a wired remote control unit installed covertly inside the
driver's console unit.
Features:
1. High-power portable multi-band jammer.
2. Upgraded jamming signal source (DDS technology) to provide
utmost efficiency.
3. Field programmability for rapid adjustment frequency and output
power.
4. Fully modular compact design with extremely high efficient
cooling system provide very good system stability even in hard climatic conditions. Also easy for
maintenance, repair and upgrade.
5. Jam up to six different jamming modules simultaneously, and
cover up to 20 different frequency bands.
6. Each module with LCD display to show its working frequency
,output power and etc.
7. Increased total RF output power up to 600 watt.
8. Equipped with a wired remote control unit. The operator can
ON/OFF each module through the wired remote controller.
9. Fully portable trolley-type case. Easy to be carried.
10. Supplied by AC mains or DC power source.
11. Backup battery system or generator system can be optional.
12. The jamming system with an active smart cooling system in a
continuously cycle working.
13. Based on our general design, we can further customize our
systems to be client-specified scenarios both for military and civil applications in order to provide the
best individual solution.
Technical Specifications
Following is the standard parameters for this prison jammer,OEM/ODM
and customrized frequencies are accpetable as well.
| Type | Vehicle Bomb Jammer |
| Frequency Range | 20-3600MHz |
| Total RF Power | 600Watt |
| Jamming Radius | 50-800M, the jamming radius still depends on the strength signal in
given area |
| Channel Frequency Number | 6 Bands, Max: 24Bands |
| Cooling System | Systematic Smart Cooling System |
| System Protection | VSWR, Over-voltage, Over-current, |
| Jamming Source | Digital Signal Source Synthesize Technology
Adjust Frequency and Output Watt |
| Remote Control | Full System Operation Control With Battery Led display |
| Antenna Type | High Gain Omnidirectional Antennas |
| External Battery | 35AH/24-28VDC |
| Jammer Module | Each Jammer module with antenna can be used as a single jammer.
All modules are controlled separately. |
| Jammer Size | 63×49.2×35.2cm |
| Jamming System Weight | 60 kg |
| Operating Temperature | -35°C ~ +80°C |
| Operating Humidity | Up to 80% |
| HS Code | 8543709200 |
| Packing | Box |
Applicable Area:
Mainly used in Prisons and other large sensitive locations such as
military or government buildings,the examination room, prisons, gas
stations, to prevent mobile bombs, oil depots, liquefied petroleum
gas stations, detention centers, interrogation rooms, courts, labor
camps, conference rooms,theaters, churches, libraries, school
dormitories, special security and confidential occasions To do, to
discuss the room, mobile vehicles, mobile politicians and business
dignitaries to defend the scene and other military powerhouse and
other places prohibited the use of mobile phones.
Terms and conditions:
Delivery Time Schedule | Delivery time is 3 weeks, Delivery will be initiated from date of
receipt of confirmed purchase order and advance remittance in our
bank. |
Payment Terms | 40% advance, 40% after one month,20% before shipping. |
Terms of Delivery | FOB HONGKONG/ USA. |
Warranty | 36 months. |
Software Updates | Free software updates will be provided for a period of 36 months. |
Extended Warranty | After 4th Year : 5% of total for each years. |
