20 - 3600MHz Portable Military Vehicle Bomb Jammer DDS High Power
Cell Phone SIgnal Jammer
Product description :
WT700157 is Bomb Jammer,IED Jammer can neutralize / prevent deadly
criminal acts such as radio controlled Car Bombs, roadside bombs,
ambush by remote IED attacks, assassinations, and remote controlled
terrorist events. In addition to implementing High Power IED
Jammers and Convoy Jammers.
WT700157 is High Power DDS Convoy Jamming System, implementing the
most effective and reliable RF jamming technology and equipped with
a fully-integrated broadband jamming system.
WT700157 can cover, continuously and simultaneously, all the RF
communication Frequencies 20MHz-6000MHz. It will be the best
solution to defend VIP convoy for vehicle mounted and some other
big area jamming quickly to be set up, like military base,
important sports events and international summits and etc.
WT700157 - Fully portable multi-band DDS Jamming system, is
designed with a ruggedized trolley type case, highly mobility. This
device is configured with 6 different jamming modules, the jamming
frequency can be more than 20Bands. Six jamming frequency modules
can be up to 600 watt output power maximum.
The WT700157 is very easy to be installed and operated. The device
can be powered by AC mains or a suitable DC power source. The
general design of the system meets military requirements and
international quality standards.
Features:
1,Upgraded jamming signal source (DDS technology) to provide utmost
efficiency.
2,Field programmability for rapid adjustment frequency and output
power.
3,Fully modular compact design with extremely high efficient
cooling system provide very good system stability even in hard
climatic conditions. Also easy for maintenance, repair and upgrade.
4,Jam up to six different jamming modules simultaneously, and cover
up to 20 different frequency bands.Each module with LCD display to
show its working frequency ,output power and etc.
5,Increased total RF output power up to 600 watt.
6,Equipped with a wired remote control unit. The operator can
ON/OFF each module through the wired remote controller.
7,Fully portable trolley-type case. Easy to be carried.
8,Supplied by AC mains or DC power source.Backup battery system or
generator system can be optional.
9,The jamming system with an active smart cooling system in a
continuously cycle working.
10,Based on our general design, we can further customize our
systems to be client-specified scenarios both for military and
civil applications in order to provide the best individual
solution.
11,Bomb Detonating and confidence leaking, resulting from Road-side
Remote Control Improvised Explosive Device (RCIED) have been
tremendous challenge in many parts of the world.
Technical Specifications
| Type | Vehicle Bomb Jammer |
| Frequency Range | 20-3600MHz |
| Total RF Power | 260-360Watt, Max: 550Watt |
| Jamming Radius | 50-800M, the jamming radius still depends on the strength signal in
given area |
| Jammer Module Number | 6 |
| Channel Frequency Number | 15Bands, Max: 24Bands |
| Cooling System | Systematic Smart Cooling System |
| System Protection | VSWR, Over-voltage, Over-current, |
| Jamming Source | Digital Signal Source Synthesize Technology
Adjust Frequency and Output Watt |
| Remote Control | Full System Operation Control With Battery Led display |
| Antenna Type | High Gain Omnidirectional Antennas |
| Number of Antennas | 6 |
| External Battery | 35AH/24-28VDC |
| Jammer Module | Each Jammer module with antenna can be used as a single jammer.
All modules are controlled separately. |
| Jammer Size | 63×49.2×35.2cm |
| Jamming System Weight | Approx.36kg |
| Operating Temperature | -35°C ~ +80°C |
| Operating Humidity | Up to 80% |
| HS Code | 8543709200 |
| Packing | Box |
Applicable Area:
• Mainly used in examination rooms, prisons, gas stations, mobile
phone bombs, oil depots, LPG stations,detention centers,
interrogation rooms, courts,
• Reform-through-labour teams, conference rooms, movie theaters,
churches, libraries, school dormitories;
• Special security and confidential occasions (confidential office,
negotiation room, mobile vehicles, mobile political and business
dignitaries guarding the scene;
• All kinds of military sites and other prohibited places to use
mobile phones.
Terms and conditions:
Delivery Time Schedule | Delivery time is 3 weeks, Delivery will be initiated from date of
receipt of confirmed purchase order and advance remittance in our
bank. |
Payment Terms | 40% advance, 40% after one month,20% before shipping. |
Terms of Delivery | FOB HONGKONG/ USA. |
Warranty | 36 months. |
Software Updates | Free software updates will be provided for a period of 36 months. |
Extended Warranty | After 4th Year : 5% of total for each years. |
