IP68 Cellular Cell Phone GSM CDMA 2G 3G 4G 5G GPSL1 WiFi2.4GHz Signal Jammer Frequency Blocker Outdoor use

Product description:

Wireless Control System: Jail Jammer System Software

1) Each unit have a control I/O Board (RF module) with hard relays (for alarm trigger) via wireless output for 2-8 data transmission to control of all functions of each unit.- to be controlled via software program on remote PC workstation by wireless

2) Each Unit be able to send Alert to the remote control PC workstation by wireless, if any of the RF frequency bands fails individually from each of the units (VSWR Alarm: Antennas Lost Connection, Module Failure)

3) All units have individual digital ID to identify them through the PC workstation.

4) The wireless data will travel to converter in main office and then convert to RS232 so it can then communicates with a PC workstation computer.

5) The software can Turn On/Off, each band, each jammer or the whole jammer system

6) Jammer Unit housing unit is waterproof and heat sink

Especially for prisons and other large sensitive locations such as military or governmental compounds. It can also use in Oil and Gas Storage Facilities and fields, Security Services, Military Units, Secret Services, Museums, Factory, Border Patrol and Drug Enforcement, Customs, etc. - Remote PC control with software to Turn each jammer, each band or the whole jammer system ON/OFF, VSWR Alarm in a wireless setup (RF module). Each unit offers a key lock support & mounting hardware

8 Bands up to 600m:

Output Interface	Output Frequency	RF Output
CH1	CDMA-800 850-894Mhz	100W
CH2	GSM-900 935-960MHz	100W
CH3	2G 1900 1805-1990MHz	100W
CH4	3G 2110-2170MHz	100W
CH5	2620-2670MHz: or 800MHz:	100W
CH6	1520-1670MHz: or 2400-2500MHz:	100W
CH7	2400-2500Mz WIFI	100W
CH8	3400-3600MHz/3600-3800MHz	100W
Antenna	8 Bands External Antenna	8 pcs
Power supply	AC220V/ 110V DC27-28V
Shielding area	400-700m @ according to signal density of mobile network
Jammer Module Number	8
Cooling System	Systematic Smart Cooling System
Dimension	72 x 45 x 32 cm
Full set weigh	42kg
Remote Control (Option)	Each band can work independently
Working time	Operation 24 hrs / 7 days a week
RF Range	Adjustable

Output Interface	Output Frequency	RF Output
CH1	450-470MHz	50W
CH2	GPS L1 1575MHz:	50W
CH3	VHF 130-180MHz:	50W
CH4	WiFi 2400-2500MHz:	50W
CH5	4G LTE 2620-2690MHz:	50W
CH6	UHF 420-480MHz:	50W

Advantages & Features

1. Each unit can jam up to 6 frequency bands simultaneously.
2. Continuous operation even in hot climates with no time limit
3. Design for outdoor installation.
4. Secure design to avoid sabotage.
5. Antenna type options - Omni or directional antennas.
6. Selection of antennas to provide more flexibility regarding jamming coverage.
7. PC remote control
