90W Military RF Signal Backpack Jammer GSM DCS PCS 3G 4G All Cell Phone Signal Jammer
Product Description:
High Power Freqeuncy Scan Convoy Jamming System, implementing the
most effective and reliable RF jammer technology and equipped with
a fully-integrated broadband jamming system. This is highly
portable and light weight. Easy for backpack.
It plays an important role to use the heavily loaded vehicle and
backpack type devices in some extreme hard situation.The operator
can carry it forward through the hills and muddy road, as well as
Climbing steep mounts and stairs avoid casualties and improve the
combat efficiency.
This is full manpack multi band Jamming system is designed with a
ruggedized case, light weight, highly mobility and reliance. This
device is configured with 6 different jamming modules, the jamming
frequency can be more than 8 Bands. Jamming frequency module can be
up to 80 watt output power maximum.
It is especially easy to install and operate: simply attach the
selected antennas and activate the desired frequency bands. The
general design of the system meets military requirements as well as
international quality standards and requirements. Our industrial
in-house quality management system guarantees highest quality
standards in terms of performance, reliable and long-life cycles.
Features:
1, Aluminum-alloy casing with high protection has high resistance
to dust, water and corroding.
2, Heat sink designing combing with the fans to make system in a
cooling status.
3, Special technology to prevent interference between each
frequency band.
4, Only interfere downlink frequency of mobile system, without
disturb normally working of Base Stations.
5, Frequency bands and output power selectable.
6, Each frequency band controlled by independent RF ON/OFF
switches.
7, Power of each frequency band can be adjustable independently.
8, Circuit protection to ensure system will not burn out in case of
antenna short circuiting or disconnection.
9, Antenna type options, directional or Omni-directional antennas
option.
10,Easy operation and installation.
11, Keep for upgrade module installation.
Specifications:
We could supply customized service by your detail requirements
about frequencies setting. 4-8 Frequency modules we can mix very flexibly.
| Output Interface | Output Frequency |
| CH1 | -CDMA: 851-960MHz /-GSM: 925-960MHz |
| CH2 | -DCS: 1805-1880MHz |
| CH3 | -PCS: 192-1990MHz |
| CH4 | -3G: 2110-2170MHz |
| CH5 | -4G Wimax: 2300-2400MHz(US) or 2620-2690MHz(EU) |
| CH6 | -4G LTE: 725-770MHz(US) or 790-826MHz(EU) |
| CH7 | -5G:3200-3600MHZ / 3600-4200MHZ |
| Jammed Signal Freqency: | CDMA,GSM,2.4G WIFI,5.8G WIFI,GPS L1,GPS L2-L5,VHF,UHF.... |
| Type: | Backpack jammer |
| Output Channel: | 8 output channels |
| Power Consumption: | Max: 220W |
| Output power: | 90watt |
| Parameter Shielding Range: | Radius 50-150 meters (-75dBm,depending on the distance of base
station in an open filed) |
| Jammer Module Number | 8 |
| HS Code: | 8543709200 |
| Packing: | Box |
| Dimension (not including antennae): | 30 *45 *15cm |
| Technical Parameters: |
| Net Weight | 12kg |
| Total Weight | 12.5kg Aviation Case included |
| Ambient Temperature | -10ºC - +50ºC |
| Relative Humidity | ≤80% |
| Power Consumption | ≤360W |
| Power Input | AC100~240V,DC24V |
| Battery | 24V,30AH,Built-in standby battery
can used for 90~180 minutes |
| Antenna Parameters | Omni antennas,gain:4~5dBi |
| Switch Control | Manually |
| Equipment Chassis | Metallic Paint |
| Cooling system | Active "smart" with integrated incoming air filter |
| Antennae type: | External high gain Omni directional Antenna |
Terms and conditions:
| Delivery Time Schedule | Delivery time is 3 weeks, Delivery will be initiated from date of
receipt of confirmed purchase order and advance remittance in our
bank. |
| Payment Terms | 40% advance, 40% after one month,20% before shipping./100%
advance,paypal,WU, etc. |
| Terms of Delivery | FOB HONGKONG/ USA. |
| Warranty | 36 months. |
| Software Updates | Free software updates will be provided for a period of 36 months. |
| Extended Warranty | After 4th Year :5% of total for each years. |
Application:
• Mainly used in examination rooms, prisons, gas stations, mobile
phone bombs, oil depots, LPG stations, detention centers,
interrogation rooms, courts,Reform-through-labour teams, conference
rooms, movie theaters,churches, libraries, school dormitories;ect.
• Special security and confidential occasions (confidential office,
negotiation room, mobile vehicles, mobile political and business
dignitaries guarding the scene;
• All kinds of military sites and other prohibited places to use
mobile phones.
