Waterproof Outdoor Fixed Cell Phone Jammer Prison Jammer GSM 3G 4G
5G Signal Jammer
Product Description:
The powerful jammer has a wide affected frequency ranges to include
CDMA/GSM, DCS/PCS, 3G, 4G LTE, 4G Wimax 5G and WiFi . It also has a
jamming range up to 500m, depending on the signal strength in the
given area. Within the range, just turn on the jammer, all wireless
connection to 2G, 3G, 4G 5G or WiFi network will be disabled at the
same time. Also, the jammer is a selectable unit. In other word,
user can choose to allow operation of one or a few of frequency
bands. Adjustment of ON or OFF any of the single bands will not
cause any disruption to the operation of others..
Applications:
High quality jammers widely use in Military Units, Prison, Police,
Bomb Disposal and Security Services.
It can also be used in places like Prison, Gas Stations, Guard,
Schools, Churches, Invigilate Meeting Room, Library, Hospitals,
Theater, Class Room and other important places and situations.
Specification:
| Output Interface | Output Frequency | RF Output |
| CH1 | CDMA 800: 850 to 894MHz | 50W |
| CH2 | GSM 900: 925 to 960MHz | 50W |
| CH3 | GSM 1800: 1805 to 1880MHz (DCS) | 50W |
| CH4 | 3G: 2110 to 2170MHz | 50W |
| CH5 | 4G LTE: (USA:725-770MHz) or (Europe:790-826MHz) | 50W |
| CH6 | 4G Wimax: (USA:2345-2400MHz) or (Europe:2620-2690MHz) | 50W |
| CH7 | 5G :3200-3600MHz/3600-3800mhZ | 50-100W |
| CH8 | WIFI2.4g: 2400-2500MHz | 50-100W |
| Total RF Power | 500Watt |
| Power supply | AC220V |
| Shielding area | 50 to 500m ( signal strength <=75dbm.) |
| Jammer Module Number | 8 |
| Antenna Type | 8pcs External high gain ( 3-4dBi ) omnidirectional ( Standard ) |
| Weight | 40.00 Kg |
| Size (length x wind x high) | 36*56*27 cm |
| Humidity | 30%-95% |
| Running Temperature | -20 to +55 Celsius Degree |
Accessories:
- Power cable
- Antennas
- User manual
Advantages and Features
· Aluminum-alloy casing with high protection has high resistance to
dust, water and corroding.
· Heat sink designing combing with the fans to make system in a
cooling status.
· Special technology to prevent interference between each frequency
band.
· Only interfere downlink frequency of mobile system, without
disturb normally working of Base Stations.
· Frequency bands and output power selectable.
· Each frequency band controlled by independent RF ON/OFF switches.
· Power of each frequency band can be adjustable independently.
· Circuit protection to ensure system will not burn out in case of
antenna short circuiting or disconnection.
· Antenna type options, directional or omni-directional antennas
option.
· Easy operation and installation.
· Keep for upgrade module installation.
· Working 24 hours/365days continuously.
