This cell phone jammer with a long jamming range of up to 500
meters
- Designed to cut off wave only in the downlink bandwidth; no
influence on the base station and repeater.
- LED display for RF output indication
- Four fans for convection and metal filter protection
- TNC antenna connecter
- IR Remote Control (8-10M)
Advantages and Features:
• Aluminum-alloy casing with high protection has high resistance to
dust, water and corroding.
• Heat sink designing combing with the fans to make system in a
cooling status.
• Special technology to prevent interference between each frequency
band.
• Only interfere downlink frequency of mobile system, without
disturb normally working of Base Stations.
• Frequency bands and output power selectable.
• Each frequency band controlled by independent RF ON/OFF switches.
• Power of each frequency band can be adjustable independently.
• Circuit protection to ensure system will not burn out in case of
antenna short circuiting or disconnection.
• Antenna type options, directional or Omni-directional antennas
option.
• Easy operation and installation.
• Keep for upgrade module installation.
• Working 24 hours/365days continuously.
Specification
- Affected Frequency Ranges: (10bands option)
| Output Interface | Output Frequency | Output power |
| CH1 | 20-100MHz | 50w |
| CH2 | 100-500MHz | 50w |
| CH3 | 500-1000MHz | 50w |
| CH4 | 1000-1500MHz | 50w |
| CH5 | 1500-2000MHz | 50w |
| CH6 | 2000-2500MHz | 50w |
| CH7 | 2500-3000MHz | 50w |
| Total RF Power | 500W |
| Power supply | AC220V |
| Shielding area | 500m @ according to signal density of mobile network |
| Jammer Module Number | 7 |
| Power consumption | 1000W |
| Weight | 25.00 Kg |
| Size (length x wind x high) | 520×580×350 mm |
| Humidity | 30%-95% |
| Running Temperature | -20 to +55 Celsius Degree |
| Battery Working Time (Option) | 2 or 3 hours |
Accessories
- High Power Cell Phone Signal Jammer
- Antennas
- Power cable
Products Application Fields
High quality jammers widely use in Military Units, Prison, Police,
Bomb Disposal and Security Services.
It can also be used in places like Prison, Gas Stations, Guard,
Schools, Churches, Invigilate Meeting Room, Library, Hospitals,
Theater, Class Room and other important places and situations.
It shall be fully tropicalization and shall be confirm to
MIL-STD 810G with: 1) Operating Temperature. -20 to 60. 2) Storage
Temperature. Not deteriorate under prolonged storage in tropical
environment. 3) Humidity. Up to 98% RH.
Completeness. The High Power IED
Jammer shall consist of the following as per Annex A. a. One (1)
Inhibitor. b. One (1) Blast Blanket.
Notices
Be sure to connect all the antennas before the power supply is
switch on. Please do not take off antenna when the machine is
working.
Antenna shall be used vertical to the ground, working more
efficiently.
Please don’t put the jammer near the water and fire, to avoid
using in the bad.
Condition of over-wet, over-hot, high voltage and high magnetism.
If the jammer cannot be charged or other unconventionality (the
indicator light doesn’t light up), please contact with the
distributor in local place. Any refit and incorrect repair is not
allowed.
Any ruin and disrepair caused by incorrect operation and
disassembly will be excluded from the repair with free of charge.
